GeoSitter Displacement
Crack Meter GS-CM06 Real-Time Crack Monitor
Designed for accurate, real-time monitoring of structural cracks in buildings, bridges, heritage structures and other critical assets — with integrated alarm functionality and over two years of battery life.
0.1 mm Accuracy
0.01 mm Sensitivity
IP68 Protection
2+ yrs Battery Life
Overview
Crack Meter GS-CM06 Real-Time Crack Monitor
The GS-CM06 Crack Meter is designed for accurate, real-time monitoring of structural cracks in buildings, bridges, heritage structures and other critical assets.
With low power consumption, remote parameter adjustment and integrated alarm functionality, it provides a practical solution for long-term crack movement monitoring and early warning applications.
Specifications
Technical Details
Specifications
Model GS-CM06
Accuracy 0.1 mm
Nonlinearity ±0.5%
Sensitivity 0.01 mm
Measuring Range ±5 mm, ±10 mm, ±25 mm, ±50 mm (customisable)
Temperature Range -20°C to 80°C
Protection Level IP68
Features
Low Power Consumption Design Increases battery life — operates for more than two years without an external power supply
Real-Time Monitoring Integrated collection and transmission system enables real-time monitoring when connected to a monitoring platform
Built-In Self-Test Alarm System When alarm thresholds are exceeded, the device performs multiple verification collections to improve monitoring reliability
Remote Parameter Configuration Sampling intervals and other operational parameters can be remotely modified through the monitoring system
IP68 Protection Level The collection terminal features a high-level IP68 protection rating for demanding environments
Compact and Easy Installation Small form factor allows for simple installation across a wide range of monitoring applications
Applications
Where the Crack Meter Excels
- Residential building crack monitoring
- Heritage and ancient structures
- Bridge piers and retaining walls
- Critical infrastructure surveillance
- Long-term crack movement and structural behaviour monitoring
- Preventative maintenance and safety assessment
- Early warning systems
