High Support Formwork Real-Time Structural Monitoring System

Advanced real-time structural monitoring for high-support formwork. Integrates wireless inclinometer, cable displacement, and axial force sensors via LoRa + 4G for continuous risk management.

LoRa + 4G Communication

0.001° Tilt Resolution

50 kN Axial Force Range

> 1 yr Battery Life

Overview

High Support Formwork Real-Time Structural Monitoring System

The High Support Formwork Monitoring System is an advanced real-time structural monitoring solution designed to improve safety, stability, and construction efficiency on high-support formwork projects. Integrating wireless inclinometer, cable displacement, and axial force monitoring technology, the system provides continuous measurement of bracket displacement, pole inclination, axial force, and structural movement.

With high-precision data collection, long battery life, LoRa + 4G communication, and seamless cloud platform integration, the system enables reliable remote monitoring and instant access to critical site data for enhanced construction risk management.

Request a Quote Download Spec Sheet

GeoSitter High Support Formwork Monitoring System — wireless inclinometer, displacement and axial force sensors

Specifications

Technical Details

Wireless Inclinometer (GS-WI01)

Model GS-WI01

Weight Approx. 620 g

Casing Material Aluminium alloy

Operating Temperature −20 °C to +80 °C

Measuring Range ±90°

Resolution 0.001°

Accuracy < ±0.01°

Communication Method LoRa + 4G

Working Voltage DC 5 V

Dimensions 101 × 86 × 66 mm (excluding bracket)

Wireless Cable Displacement Monitor (GS-WCDM01)

Model GS-WCDM01

Communication LoRa + 4G

Operating Temperature −20 °C to +80 °C

Weight Approx. 733 g

Measuring Range 0 to 500 mm

Resolution 0.1 mm

Accuracy < ±1 mm

Working Voltage DC 5 V

Casing Material Aluminium alloy

Dimensions 101 × 86 × 66 mm (excluding bracket)

Wireless Axial Force Monitor (GS-WAFM01)

Model GS-WAFM01

Weight Approx. 1357 g

Casing Material Aluminium alloy

Operating Temperature −20 °C to +80 °C

Measuring Range 0 to 50 kN

Resolution 1 N

Accuracy < ±0.5%

Communication LoRa + 4G

Working Voltage DC 5 V

Dimensions 180 × 85 × 46 mm (excluding stress surface)

Features

Integrated Monitoring System Includes wireless inclinometer, wireless axial force monitor, wireless laser distance meter, and wireless terminal

Comprehensive Monitoring Measures bracket vertical displacement, horizontal displacement, pole tilt, and axial force

High Precision Monitoring Accurate data collection with high precision and wide measuring range

Customisable Parameters Supports customisation of collection intervals, baud rates, and other operating parameters

Real-Time Data Transmission Real-time collection, transmission, and instant display of monitoring data on tablets

Cloud Platform Compatibility Supports integration with various cloud monitoring platforms for convenient remote access

Long Battery Life Ultra-low power consumption with battery life exceeding one year when collecting data every 5 minutes

Rechargeable System Rechargeable power design supports long-term field operation

Open API Integration Open cloud platform API enables seamless integration with user-specific platforms

Rugged Construction IP67/IP65 protection rating for reliable outdoor operation

Wide Operating Temperature Designed to operate in temperatures from −20 °C to 70 °C

Applications

Where the High Support Formwork Excels

High-support formwork safety monitoring
Bracket vertical and horizontal displacement tracking
Pole tilt and inclination surveillance
Axial force monitoring on shoring members
Real-time construction risk management
Remote site monitoring via cloud platform
Tablet-based on-site instant data display
